Pulleys
5V section QD bushed
PHP 4-5V1180-E
5V section QD bushed
PHP 4-5V1180-E
| Pitch diameter (mm) | 297.18 |
| Pitch diameter (in) | 11.7 |
| Outside diameter (mm) | 299.72 |
| Outside diameter (in) | 11.8 |
| Pulley type | B-2 |
| Bushing no. | E |
| Min. bore (mm) | 22.22 |
| Min. bore (in) | 0.87 |
| Max. bore (mm) | 88.9 |
| Max. bore (in) | 3.5 |
| F (in) | 3 (1/16) |
| E (in) | (11/32) |
| L (in) | 2 (3/4) |
| M (in) | (1/32) |
| Weight (lbs) | 72.8 |
