Pulleys
HiTD Taper bushed 8M
PHP 22-8M-20TB
HiTD Taper bushed 8M
PHP 22-8M-20TB
| No. of teeth | 22 |
| Pitch diameter (mm) | 56.02 |
| Outside diameter (mm) | 54.65 |
| Pulley type | 4F |
| Bushing no. | 1008 |
| Min. bore (mm) | 9 |
| Max. bore (mm) | 25 |
| Flange A (mm) | 65 |
| H | - |
| F | 28 |
| K | 6 |
| L | 22 |
| M | - |
| Weight (kg) | 0.24 |
