Sprockets
Metric Triplex, Taper Bushed
PHS 12B-3TB76
Metric Triplex, Taper Bushed
PHS 12B-3TB76
| Pitch P (mm) | 19.05 |
| Pitch P (in) | 0.75 |
| No. of teeth | 76 |
| Pitch diameter (mm) | 460.99 |
| Pitch diameter (in) | 18.15 |
| Min. bore (mm) | 25 |
| Min. bore (in) | 0.98 |
| Max. bore (mm) | 75 |
| Max. bore (in) | 2.95 |
| Hub H (mm) | 51 |
| Hub H (in) | 2.01 |
| Hub L (mm) | 140 |
| Hub L (in) | 5.51 |
| Weight (kg) | 25.5 |
| Weight (lbs) | 56.22 |
| Bushing no. | 51 |
