Sprockets
Metric Triplex, Taper Bushed
PHS 16B-3TB25
Metric Triplex, Taper Bushed
PHS 16B-3TB25
| Pitch P (mm) | 25.4 |
| Pitch P (in) | 1 |
| No. of teeth | 25 |
| Pitch diameter (mm) | 202.66 |
| Pitch diameter (in) | 7.98 |
| Min. bore (mm) | 35 |
| Min. bore (in) | 1.38 |
| Max. bore (mm) | 100 |
| Max. bore (in) | 3.94 |
| Hub H (mm) | 65 |
| Hub H (in) | 2.56 |
| Hub L (mm) | - |
| Hub L (in) | - |
| Weight (kg) | 9.8 |
| Weight (lbs) | 21.61 |
| Bushing no. | 65 |
